4 Multimode LC Fiber Optic Adapter Reduce Fiber Optic Couplers For CATV / FTTX

4 Multimode LC Fiber Optic Adapter Reduce Fiber Optic Couplers For CATV / FTTX

Brand Name:	HACEN
MOQ:	5000PCS
Price:	Negotiable
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	Depends on the cavities and toolings

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

RoHs ,ISO9001,ISO14001,ISO45001

Document:

MPO simplex.pdf

Adapter Type:

Connector Material:

Plastic

Use:

CATV/FTTX

Insert Loss:

≤0.20dB

Rohs Compliancy Status:

Compliant

Warranty:

2 Years

Aligment Sleeve Material:

Ceramic

Housing Materials:

Plastic

Color:

Blue, Beige, Green, Black

Packaging Details:

CARTON

Supply Ability:

Depends on the cavities and toolings

Highlight:

LC Fiber Optic Adapter

FTTX Fiber Optic Adapter

Product Description

4 Multimode LC Fiber Optic Adapters Reduce Fiber optic couplers

LC fiber optic adapter, also called a fiber optic coupler, is a small device designed to terminate or link the fiber optic cables or fiber optic connectors between two fiber optic lines.

Please note that this document is for reference purposes only and may not fully correspond to the actual product. To ensure accuracy and prevent any information leakage .please contact us directly for the correct documentation.

Features
- 100% tested on optical performance (Insertion Loss & Return Loss)
- End-face geometry requirement complies to Telcordia GR-326-CORE
- For end-to-end fiber cable connectivity

- Good Temperature characteristic

- Good repeatability

Applications

- CATV

- Active device termination

- Telecommunication networks

- Metro networks

- Local Area Networks (LANs)

- Data processing networks

Environmental & Mechanical Data

Operating Temperature	-40 to +75º C
Storage Temperature:	-40 to +85º C
Temperature Cycling (61300-2-18)	-40 to +75º C, 40 cycles=0.2dB change
High temperature (61300-2-18)	70˚c for 96Hrs, <0.4dB change
Damp Heat (61300-2-19)	40º C at 93%RH for 96 Hrs, <0.4dB change
Vibration-Mated Pair (61300-2-1)	10-55Hz, 1.5mm P to P <0.2dB change
Mating Durability (61300-2-2)	500 Mating Cycles, clean every 25, <0.2dB change
Adapter Material	Plastic
Adapter Color	Black,Blue,Green,Aqua,

FAQ

1. What are we selling ?
Fiber optic connectors and adapters. like LC .MPO.SC.E2OOO…..also you can set up new mold with us. We offer service from mold design to final plastic molding injection

2. How can we guarantee quality?

From raw materials to final shipment, we can offer inspection report or related certifications.

3. Why us ?
We focus on the fiber optical components for over 15 years , such as adapters, connectors and ONU boxes . experienced in molding injection for over 20years like consumer plastic ,auto plastic ,

4. What materials are we using ?

TPEE, TPU, PEI, PBT, nylon, LCP, PPS, POM, PC, ABS and some others too.

5. Do you support customization?

Yes , both OEM and ODM are available.
