High Precision Mold Fiber Optic To MPO Adapter Plastic Pigatail Connectors

High Precision Mold Fiber Optic To MPO Adapter Plastic Pigatail Connectors

Brand Name:	HACEN
MOQ:	5000PCS
Price:	Negotiable
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	Depends on the cavities and toolings

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

RoHs ,ISO9001,ISO14001,ISO45001

Packing:

Ploybag/Blister Box

Adapter Type:

MPO

House Material:

PBT ABS

Compatibility:

Singlemode And Multimode

Use:

Patch Cord, PL C Splitter, Pigtail,

Product Type:

Adapter

Operating Temperature:

-40°C To +85°C

Return Loss:

>50dB

Packaging Details:

CARTON

Supply Ability:

Depends on the cavities and toolings

Highlight:

High Precision MPO Adapter

MPO Adapter Plastic

Product Description

High Precision Mold Design Fiber Optic To MPO Adapter Pigatail Connectors

Fiber Optic Adaptors are color coded allowing easy identification of the adaptor type.

Features
- 100% tested on optical performance (Insertion Loss & Return Loss)
- End-face geometry requirement complies to Telcordia GR-326-CORE
- Female to female & male to female adapters available
- Hybrid, Shuttered and Metal adapters available
- Coloured for easy indentification

- Low insertion and return loss and back reflection

Applications

- Active device termination

- Telecommunication networks

- Metro networks

- Local Area Networks (LANs)

- Test equipment

Environmental & Mechanical Data

Operating Temperature	-40 to +75º C
Storage Temperature:	-40 to +85º C
Temperature Cycling (61300-2-18)	-40 to +75º C, 40 cycles=0.2dB change
High temperature (61300-2-18)	70˚c for 96Hrs, <0.4dB change
Damp Heat (61300-2-19)	40º C at 93%RH for 96 Hrs, <0.4dB change
Vibration-Mated Pair (61300-2-1)	10-55Hz, 1.5mm P to P <0.2dB change
Mating Durability (61300-2-2)	500 Mating Cycles, clean every 25, <0.2dB change
Adapter Material	Plastic
Adapter Color	Black,Blue,Green,Aqua,

FAQ

1. What are we selling ?
Fiber optic connectors and adapters. like LC .MPO.SC.E2OOO…..also you can set up new mold with us. We offer service from mold design to final plastic molding injection

2. How can we guarantee quality?

From raw materials to final shipment, we can offer inspection report or related certifications.

3. Why us ?
We focus on the fiber optical components for over 15 years , such as adapters, connectors and ONU boxes . experienced in molding injection for over 20years like consumer plastic ,auto plastic ,

4. What materials are we using ?

TPEE, TPU, PEI, PBT, nylon, LCP, PPS, POM, PC, ABS and some others too.

5. Do you support customization?

Yes , both OEM and ODM are available.
